The NDR110 series planetary gearboxes are designed and machined as a single unit with special tapered roller bearings to provide high radial load, high torque, ultra-precision, and small size. The ND series uses in highly rigid industries such as fiber optic laser equipment, floor track equipment, robot seventh axis, Parallel robots (spider hand) machine tools, and rotating arms.
Product Name: High Precision Planetary Reducer
Product Series: NDR110 Series
Product features: high torque, high load, ultra-precision, small size
Product Description:
Integrated design concept with high-strength bearings ensure the product itself is durable and efficient
A variety of output ideas such as shaft output, flange and gear are available.
1 arc minute ≤ backlash ≤ 3 arc minutes
Reduction ratios ranging from 3 to 100
Frame design: increases torque and optimizes power transmission
Optimised selection of oil seals: reduces friction and laminate transmission efficiency
Protection class IP65
Warranty: 2 years
Our Advantages
High torque
High load
ultra-precision
Small size
Detailed Photos
Product Parameters
| Segment number | Single segment | ||||||||
| Ratio | i | 25 | 35 | 40 | 50 | 70 | 100 | 140 | 200 |
| Rated output torque | Nm | 310 | 280 | 250 | 310 | 280 | 210 | 280 | 210 |
| Emergency stop torque | Nm | Three times of Maximum Output Torque | |||||||
| Rated input speed | Rpm | 4000 | |||||||
| Max input speed | Rpm | 8000 | |||||||
| Ultraprecise backlash | arcmin | ≤4 | |||||||
| Precision backlash | arcmin | ≤7 | |||||||
| Standard backlash | arcmin | ≤9 | |||||||
| Torsional rigidity | Nm/arcmin | 82 | |||||||
| Max.bending moment | Nm | 430 | |||||||
| Max.axial force | N | 2990 | |||||||
| Service life | hr | 30000(15000 under continuous operation) | |||||||
| Efficiency | % | ≥92% | |||||||
| Weight | kg | 9.8 | |||||||
| Operating Temperature | ºC | -10ºC~+90ºC | |||||||
| Lubrication | Synthetic grease | ||||||||
| Protection class | IP64 | ||||||||
| Mounting Position | All directions | ||||||||
| Noise level(N1=3000rpm,non-loaded) | dB(A) | ≤68 | |||||||
| Rotary inertia | Kg·cm² | 2.25 | 1.87 | ||||||
Applicable Industries
Packaging Machinery Mechanical Hand Textile Machinery
Non Standard automation Machine Tool Printing Equipment
Certifications
Company Profile
DESBOER (HangZhou) Transmission Technology Co., Ltd. is a subsidiary of DESBOER (China), which is committed to the design, development, customized production and sales of high precision planetary reducer as 1 of the technology company. Our company has over 10 years of design, production and sales experience, the main products are the high precision planetary reducer, gear, rack, etc., with high quality, short delivery period, high cost performance and other advantages to better serve the demand of global customers. It is worth noting that we remove the intermediate link sale from the factory directly to customers, so that you can get the most ideal price and also get our best quality service simultaneously.
About Research
In order to strengthen the advantages of products in the international market, the head company in Kyoto, Japan to established KABUSHIKIKAISYA KYOEKI, mainly engaged in the development of DESBOER high precision planetary reducer, high precision of transmission components such as the development work, to provide the most advanced design technology and the most high-quality products for the international market.
/* January 22, 2571 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(“,”).forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
| Application: | Motor, Machinery, Marine, Agricultural Machinery, CNC Machine |
|---|---|
| Function: | Change Drive Torque, Speed Changing, Speed Reduction |
| Layout: | Plantery Type |
| Hardness: | Hardened Tooth Surface |
| Installation: | All Directions |
| Step: | Double-Step |
| Customization: |
Available
| Customized Request |
|---|
What is a Gearbox and How Does It Work?
A gearbox is a mechanical device that transmits power and changes the speed or torque of a rotating input shaft to a different output shaft. It is commonly used in various machines and equipment to control the speed and direction of motion.
Here’s how a gearbox works:
- Input Shaft: The gearbox receives rotational energy from an input shaft connected to a power source, such as an electric motor or an engine.
- Gears: Inside the gearbox are a set of gears with different sizes. These gears mesh with each other, and their arrangement determines the gear ratio, which defines how many revolutions the output shaft will make for a given rotation of the input shaft.
- Output Shaft: The output shaft is connected to the machinery or equipment that needs to be powered. As the gears rotate, the motion and power are transmitted from the input shaft to the output shaft.
- Gear Ratio: By selecting different gear combinations, the gearbox can change the speed and torque of the output shaft. A higher gear ratio results in higher torque and lower speed, while a lower gear ratio provides higher speed and lower torque.
Gearboxes play a crucial role in various applications, including automobiles, industrial machinery, robotics, and more, enabling efficient power transmission and speed control.
